Our Facility

Our 20,000 square foot facility houses the following:

MANUAL LATHES

Torni Tacchi Castano P. FTA 51

Type: Sliding gap bed engine lathe
Max turning diameter: 32 inches
Max turning length: 200 inches
Swing over bed: 45 inches / 74 inches in gap
Distance between centers: 216 inches with gap in / 336 inches with gap out
Spindle bore: 4.625 inches

Clausing Colchester Magnum 1250

Type: Removable gap engine lathe
Max turning diameter: 15.375 inches
Max turning length: 120 inches
Swing over bed: 25 inches / 36 inches in gap
Distance between centers: 120 inches
Spindle bore: 4.75 inches

Bridgeport 20/25-15L

Type: Engine Lathe
Max turning diameter: 17 inches
Max turning length: 60 inches
Swing over bed: 25 inches
Distance between centers: 80 inches
Spindle bore: 4 inches

American Turnmaster PHL 1500

Type: Removable gap engine lathe
Max turning diameter: 12 inches
Max turning length: 40 inches
Swing over bed: 17 inches /28 inches in gap
Distance between centers: 60 inches
Spindle bore: 3.125 inches

MANUAL MILLS

Rambaudi KVO (2)

Type: Vertical/horizontal milling machines, 50 taper
Table size: 63”x 14 ½”
X travel: 49 inches
Y travel: 15.75 inches
Z travel: 16.5 inches

Rambaudi MS-3

Type: Vertical/horizontal milling machine, 40 taper
Table size: 12”x 52”
X travel: 48 inches
Y travel: 18 inches
Z travel: 20 inches

Shibaura MDL BFT-13C

Type: Boring mill, 5.125” spindle
Table size: 96”x 47”
Table Capacity: 25,000 lbs
X travel: 96 inches
Y travel: 72 inches
Z travel: 84 inches
Additional: 48”x 60” Gidding and Lewis air lift rotary table

CNC MILLING MACHINES

Lucas 40T86

Type: CNC boring mill, 6” spindle
Table size: 110”x 48”
Table Capacity: 25,000 lbs
X travel: 96 inches
Y travel: 48 inches
Z travel: 72 inches
Controller: Allen-Bradley 9/series
Additional: 59”x 59” rotary table

Rambaudi Ram-Mill

Type: CNC twin-spindle vertical mill
Table size: 60”x 20”
X travel: 42 inches
Y travel: 16 inches
Z travel: 16 inches
Controller: Heidenhain

Doosan REVO 51P

Type: CNC vertical machining center
Tool changer capacity: 30 tools
Table size: 53.1”x 20.5”
X travel: 43.3 inches
Y travel: 20 inches
Z travel: 23.2 inches
Controller: Fanuc series Oi-MB
Additional: 4th axis rotary table
CNC TURNING CENTERS

Doosan S310N

Type: CNC turning center
Tool changer capacity: 12 tools
Max turning diameter: 12.2 inches
Max turning length: 18.1 inches (recommend 16.1 inches)
Swing over bed: 20.5 inches
X travel: 7.3 inches
Z travel: 19.7 inches
Spindle bore: 2.9375 inches
Controller: Fanuc

Cincinnati Milacron Cinturn 18U-80

Type: CNC turning center
Tool changer capacity: 12 tools
Max turning diameter: 18.25 inches
Max turning length: 84 inches
Swing over bed: 30.38 inches
X travel: 30 inches
Z travel: 84 inches
Spindle bore: 4 inches
Controller: Vickers Acramatic 2100

Okuma Captain L470M

Type: CNC turn mill
Tool changer capacity: 12 tools
Max turning diameter: 16.54 inches
Max turning length: 25.59 inches
Swing over bed: 24.41 inches
X travel: 11.81 inches
Z travel: 26.57 inches
Spindle bore: 4.33 inches
Controller: Okuma OSP-P200L

OTHER

Challenger Water Table w/Plasma & Oxy-Fuel Cutting Torches

Type: Hypotherm Edge Pro Ti CNC Controller
Table size: 10’ x 20’
Plasma capacity: 100 amp or 200 amp maximum power source. Ability to cut up to ¾” thick aluminum and 1” thick steel.
Oxy-Fuel capacity: (2) Harris torches with ability to cut simultaneously. Ability to cut up to 9” thick steel.

Dreis & Krump H-400-10

Type: 500 Ton Press Brake

Version T-76

Type: 400 Ton Hydraulic Press Brake

American Hercules

Type: Shear
Blade Length: 12’L
Shearing Capacity: ½” thick material

Cullen-F, 140

Type: Weld Positioner

LIFTING CAPACITY

20 Ton Double Girder Crane

Location: South Machine Shop Bay

10 Ton Double Girder Crane

Location: North Machine Shop Bay

10 Ton Double Girder Crane

Location: South East Fab Shop

5 Ton Single Girder Crane

Location: North Weld Shop

10 Ton Double Girder Crane

Location: North Weld Shop

* Selected additional work stations utilize jib cranes
